برد NUCLEO-H503RB

NUCLEO-H503RB - STM32 Nucleo-64 development board with STM32H503RBT6 MCU, supports Arduino and ST Morpho connectivity

Category
   Development Boards, Kits, Programmers
   Evaluation Boards - Embedded - MCU, DSP
Mfr
   STMicroelectronics
Series
    STM32H5
Package
   Bulk
Product Status
   Active
Type
   MCU 32-Bit
Core Processor
   ARM® Cortex®-M33
Platform
   Nucleo-64
Utilized IC / Part
    STM32H503
Mounting Type
   Fixed
Contents
   Board(s)
Board Type
   Evaluation Platform
Operating System
   -
Interconnect System
   Arduino R3 Shield, ST Morpho
Suggested Programming Environment
   IAR EW, Keil MDK, STM32Cube
Note
   -
Base Product Number
    STM32H503

Description

The STM32 Nucleo-64 board provides an affordable and flexible way for users to try out new concepts and build prototypes by choosing from the various combinations of performance and power consumption features, provided by the STM32 microcontroller. For the compatible boards, the external SMPS significantly reduces power consumption in Run mode.

The ARDUINO® Uno V3 connectivity support and the ST morpho headers allow the easy expansion of the functionality of the STM32 Nucleo open development platform with a wide choice of specialized shields.

The STM32 Nucleo-64 board does not require any separate probe as it integrates the ST-LINK debugger/programmer.

The STM32 Nucleo-64 board comes with the STM32 comprehensive free software libraries and examples available with the STM32Cube MCU Package.

    All features
        Common features
            STM32 microcontroller in an LQFP64 or LQFP48 package
            1 user LED shared with ARDUINO®
            1 user and 1 reset push-buttons
            32.768 kHz crystal oscillator
            Board connectors:
                ARDUINO® Uno V3 expansion connector
                ST morpho extension pin headers for full access to all STM32 I/Os
            Flexible power-supply options: ST-LINK USB VBUS or external sources
            On-board ST-LINK debugger/programmer with USB re-enumeration capability: mass storage, Virtual COM port, and debug port
            Comprehensive free software libraries and examples available with the STM32Cube MCU Package
            Support of a wide choice of Integrated Development Environments (IDEs) including IAR Embedded Workbench®, MDK-ARM, and STM32CubeIDE
        Board-specific features
            External SMPS to generate Vcore logic supply
            24 MHz or 48 MHz HSE
            User USB Device full speed, or USB SNK/UFP full speed
            Cryptography
            Board connectors:
                External SMPS experimentation dedicated connector
                USB Type-C®, Micro-B, or Mini-B connector for the ST-LINK
                USB Type-C® user connector
                MIPI® debug connector
