میکروکنترلر stm32f072c8t6 /اورجینال -New and original+گارانتی

میکروکنترلر stm32f072c8t6 /اورجینال



 Family Name:
           STM32F
 Core Processor:
           ARM Cortex M0
 Program Memory Type:
           Flash
 Flash Size (Bytes):
           64 kB
 RAM Size:
           16 kB
 Speed:
           48 MHz
 No of I/O Lines:
           37
 InterfaceType / Connectivity:
           CAN / HDMI-CEC / I2C / IrDA / LIN / SPI / UART / USART / USB
 Peripherals:
           DMA / I2S / POR / PWM / Watchdog
 Supply Voltage:
           1.65 to 3.6 V
 Operating Temperature:
           -40 to +85 °C
 On-Chip ADC: 13-chx12-bit
 On-Chip DAC: 2-chx12-bit
 Watchdog Timers: 1

Categories:
      Integrated Circuits (ICs)
      Embedded - Microcontrollers
Manufacturer:
    STMicroelectronics
Series:
    STM32 F0
Packaging:
     Tray
Part Status:
     Active
Core Processor:
     ARM® Cortex®-M0
Core Size :
    32-Bit
Speed :
    48MHz
Connectivity :
    CAN, HDMI-CEC, I²C, IrDA, LIN, SPI, UART/USART, USB
Peripherals:
     DMA, I²S, POR, PWM, WDT
Number of I/O:
     37
Program Memory Size :
    64KB (64K x 8)
Program Memory Type :
    FLASH
EEPROM Size :
    -
RAM Size:
     16K x 8
Voltage - Supply (Vcc/Vdd) :
    1.65 V ~ 3.6 V
Data Converters :
    A/D 10x12b, D/A 2x12b
Oscillator Type :
    Internal
Operating Temperature :
    -40°C ~ 85°C (TA)
Package / Case :
    48-LQFP
Supplier Device Package :
    48-LQFP (7x7)
