at45db161d-su-اورجینال -New and original+گارانتی

Features
• Single 2.5V - 3.6V or 2.7V - 3.6V Supply
• Atmel RapidS Serial Interface: 66MHz Maximum Clock Frequency
– SPI Compatible Modes 0 and 3
• User Configurable Page Size
– 512-Bytes per Page
– 528-Bytes per Page
– Page Size Can Be Factory Pre-configured for 512-Bytes
• Page Program Operation
– Intelligent Programming Operation
– 4,096 Pages (512-/528-Bytes/Page) Main Memory
• Flexible Erase Options
– Page Erase (512-Bytes)
– Block Erase (4-Kbytes)
– Sector Erase (128-Kbytes)
– Chip Erase (16-Mbits)
• Two SRAM Data Buffers (512-/528-Bytes)
– Allows Receiving of Data while Reprogramming the Flash Array
• Continuous Read Capability through Entire Array
– Ideal for Code Shadowing Applications
• Low-power Dissipation
– 7mA Active Read Current Typical
– 25μA Standby Current Typical
– 15μA Deep Power Down Typical
• Hardware and Software Data Protection Features
– Individual Sector
• Sector Lockdown for Secure Code and Data Storage
– Individual Sector
• Security: 128-byte Security Register
– 64-byte User Programmable Space
– Unique 64-byte Device Identifier
• JEDEC Standard Manufacturer and Device ID Read
• 100,000 Program/Erase Cycles Per Page Minimum
• Data Retention – 20 Years
• Industrial Temperature Range
• Green (Pb/Halide-free/RoHS Compliant) Packaging Options
