oled 0.96 inch OLED display module 128x64 ssd1306 IIC / Yellow&Blue

ماژول OLED 0.96 inch Yellow & Blue با رزولیشن 128x64 و با درایور SSD1306 و IIC Interface

نوع ارتباط اولد در این ماژول به صورت سوکت FFC هست.

1> GND(Power ground)
2> VCC(Power supply3.3~5V)
3> DO(SPI clock line for SPI interface,IIC clock line for IIC interface)
4>D1 (SPI data line for SPI interface ,IIC data line for IIC interface)
5> RES (OLED reset,OLED needs to be reset once after power-on)
6> DC (SPI data / command selection foot,IC interface used to set IIC address)
7>CS(OLED SPI chip selection,Bottom level effective,If you do not want to use, you must ground)

important:OLED display is different from LCD;OLED is spontaneous light;So no backlight,The screen will not react if only the power is applied.;There must be a program that operates correctly to have a display.This is a big concern.
